QNAP TS-831XU-RP-4G NAS, 8BAY (NO DISK), 4GB, AL-314 QC, USB,GbE(2),10GbE SFP+(2),2U,2YR
Processor
AL-314 Quad-Core 1.7 GHz ARM® Cortex-A15 CPU
Hardware Encryption Accleration
✔
System Memory
4GB DDR3 (1 x 4GB)
Maximum Memory
16GB
Memory Slots
2 x SODIMM DDR3
(Note: For dual-DIMM configurations, you must use a pair of identical DDR3 RAM modules.)
Flash Memory
512MB
Drive Type
8 x 3.5"/2.5" SATA 6Gb/s HDDs/SSDs
10GbE LAN
2 x 10 Gigabit SFP+ LAN ports
GbE LAN
2 x Gigabit RJ45 LAN ports
USB
4 x USB 3.0 ports
PCIe Slot
1 x PCIe Gen2 (x2)
LED
Status/Power, LAN, HDD 1-8
Button
Power, Reset
Other
Kensington security slot, console port
Dimension (HxWxD)
89 x 482 x 534 mm
3.5 x 18.98 x 21.02 inch
Weight
Net: 12.56 kg (27.69 lbs)
Gross: 14.64 kg (32.28 lbs)
Operating Temperature
0-40˚C
Relative Humidity
5~95% RH non-condensing, wet bulb: 27˚C
Noise Level
48.3 dB(A)*
Power Consumption
HDD standby: 37.15W
In operation: 64.36W
(with 8 x 2TB HDDs installed)
Power
ATX 250W, 100-240V AC, 5A-2.5A, 50Hz-60Hz (x2)
Fan
2 x 7cm system fan (12V DC)
